CBB capacitor 630V 223J P=10mm Chinese manufacturer

CBB21 Polyester Film Capacitor
223J 630V Film Capacitor
Package: Bulk and Tape
Size(T*H*W):5*10*13mm
Can withstand 200 times of destructive charge and discharge

Description

CBB capacitor 630V 223J P=10mm

CBB capacitor 630V 223J P=10mm is a non-inductive structure. It is made of metallized polypropylene film as the electrolyte and the electrode is wound. The wire is tinned copper clad steel wire, encapsulated with flame retardant epoxy resin. Good self-healing and long life. Suitable for DC and VHF level signals. DC, bypass and coupling. Widely used in filter skin, noise reduction, pulse, resonance and step-down circuits, high-frequency large current occasions, especially suitable for various types of energy-saving lamps and electronic ballasts.

CBB21 capacitor 223J 630V

Type : metalized polyester film capacitor
Colour：Orange red
Capacitance:0.022uf （273)
Rated Voltage:630V
Capacitance Tolerance: ±5%(J),±10%(K)
Lead Pitch(mm):10.0mm
Temperature Range: -25 To 85°C
W: 13.0mm
H: 10mm
T: 5mm
P±1： 10.0mm
