1. The Importance of Equipment Installation Tracking 💐The DC converter station usually shoulders the important task of interconnecting large-scale power grids and transmitting electric energy with high power. The safe and stable operation of a single station often determines the safe and stable operation of the large power grid system, and the safe and stable operation [...]
Power capacitor are the most important equipment in AC and DC filters and shunt capacitor devices in DC converter stations. Understanding and mastering the production process of capacitors has certain practical significance for us to better maintain equipment and deal with faults during equipment operation. 1. Overview 🌱Capacitors have strict production processes in equipment manufacturers, and [...]
🌱China's HVDC transmission projects have developed rapidly after 2000, and the rapid development of HVDC transmission projects has led to a rapid increase in the demand for different types of power capacitors in converter stations. For a DC transmission project, the capacity of the power capacitors used is far from the capacity of the capacitors required [...]
1. Composition and structure of filter and parallel capacitors device 🍏The AC filter consists of high and low voltage capacitor banks (capacitor towers), reactors, resistors, lightning arresters, current transformers (oil-filled, silicone rubber, photocurrent transformers) and other metal connectors, supports, protective parts, etc. composition. The AC filters often used in the design of DC converter stations include [...]
🍏The configuration of AC and DC capacitor filters in the converter station is mainly based on the harmonic components and reactive power requirements of the AC and DC sides of the converter station, and the configuration of the parallel capacitors is based on the reactive power requirements of the AC side of the converter station. During [...]
